spring cloud 二代架构依赖组件 docker全配置放送

 1version: '2'
 2
 3services:
 4  apollo-quick-start:
 5    image: nobodyiam/apollo-quick-start
 6    container_name: apollo-quick-start
 7    depends_on:
 8      - apollo-db
 9    ports:
10      - "8080:8080"
11      - "8070:8070"
12    links:
13      - apollo-db
14
15  apollo-db:
16    image: mysql:5.7
17    container_name: apollo-db
18    environment:
19      TZ: Asia/Shanghai
20      MYSQL_ALLOW_EMPTY_PASSWORD: 'yes'
21    depends_on:
22      - apollo-dbdata
23    ports:
24      - "13306:3306"
25    volumes:
26      - ./sql:/docker-entrypoint-initdb.d
27    volumes_from:
28      - apollo-dbdata
29
30  apollo-dbdata:
31    image: alpine:latest
32    container_name: apollo-dbdata
33    volumes:
34      - /var/lib/mysql

 1version: "2"
 2services:
 3  nacos:
 4    image: nacos/nacos-server:latest
 5    container_name: nacos-standalone-mysql
 6    env_file:
 7      - ./env/nacos-standlone-mysql.env
 8    volumes:
 9      - ./standalone-logs/:/home/nacos/logs
10      - ./init.d/custom.properties:/home/nacos/init.d/custom.properties
11    ports:
12      - "8848:8848"
13      - "9555:9555"
14    depends_on:
15      - mysql
16    restart: on-failure
17  mysql:
18    container_name: mysql
19    image: nacos/nacos-mysql:5.7
20    env_file:
21      - ./env/mysql.env
22    volumes:
23      - ./mysql:/var/lib/mysql
24    ports:
25      - "3308:3306"

 1version: '2'
 2services:
 3  #redis容器
 4  redis:
 5    #定义主机名
 6    container_name: redis
 7    #使用的镜像
 8    image: redis:6.0.8
 9    #容器的映射端口
10    ports:
11      - 6379:6379
12    command: redis-server /etc/conf/redis.conf
13    #定义挂载点
14    volumes:
15      - ./data:/data
16      - ./conf:/etc/conf
17    #环境变量
18    privileged: true
19    environment:
20      - TZ=Asia/Shanghai
21      - LANG=en_US.UTF-8

 1version: '2'
 2
 3services:
 4  #Service for nameserver
 5  namesrv:
 6    image: apacherocketmq/rocketmq-nameserver:4.5.0-alpine-operator-0.3.0
 7    container_name: rmqnamesrv
 8    ports:
 9      - 9876:9876
10    volumes:
11      - ./data/namesrv/logs:/home/rocketmq/logs
12    command: sh mqnamesrv
13    environment:
14      TZ: Asia/Shanghai
15      JAVA_OPT_EXT: "-server -Xms512m -Xmx512m -Xmn256m"
16
17  #Service for broker
18  broker:
19    image: apacherocketmq/rocketmq-broker:4.5.0-alpine-operator-0.3.0
20    container_name: rmqbroker-a
21    depends_on:
22      - namesrv
23    ports:
24      - 10909:10909
25      - 10911:10911
26      - 10912:10912
27    environment:
28      NAMESRV_ADDR: namesrv:9876
29      JAVA_OPT_EXT: "-server -Xms512m -Xmx512m -Xmn256m"
30    volumes:
31      - ./data/broker/logs:/home/rocketmq/logs
32      - ./data/broker/store:/home/rocketmq/store
33      - ./data/broker/conf/broker.conf:/opt/rocketmq-4.7.1/conf/broker.conf
34
35    command: sh mqbroker -c /opt/rocketmq-4.7.1/conf/broker.conf
36
37 #Service for another broker -- broker1
38  broker1:
39    image: apacherocketmq/rocketmq-broker:4.5.0-alpine-operator-0.3.0
40    container_name: rmqbroker-b
41    depends_on:
42      - namesrv
43    ports:
44      - 10929:10909
45      - 10931:10911
46      - 10932:10912
47    environment:
48      NAMESRV_ADDR: namesrv:9876
49      JAVA_OPT_EXT: "-server -Xms512m -Xmx512m -Xmn256m"
50    volumes:
51      - ./data1/broker/logs:/home/rocketmq/logs
52      - ./data1/broker/store:/home/rocketmq/store
53      - ./data1/broker/conf/broker.conf:/opt/rocketmq-4.7.1/conf/broker.conf
54    command: sh mqbroker -c /opt/rocketmq-4.7.1/conf/broker.conf
55
56  rmqconsole:
57    image: styletang/rocketmq-console-ng
58    container_name: rmqconsole
59    ports:
60      - 8180:8080
61    environment:
62        TZ: Asia/Shanghai
63        JAVA_OPTS: "-Drocketmq.namesrv.addr=namesrv:9876 -Dcom.rocketmq.sendMessageWithVIPChannel=false"
64    depends_on:
65      - namesrv

 1## ./data/broker/conf/broker.conf
 2brokerClusterName = DefaultCluster
 3brokerName = broker-abroker
 4Id = 0
 5deleteWhen = 04
 6fileReservedTime = 48
 7brokerRole = ASYNC_MASTER
 8flushDiskType = ASYNC_FLUSH
 9
10### ./data1/broker/conf/broker.conf
11brokerClusterName = Default
12ClusterbrokerName = broker-bbroker
13Id = 0
14deleteWhen = 04
15fileReservedTime = 48
16brokerRole = ASYNC_MASTER
17flushDiskType = ASYNC_FLUSH

 1version: "3.1"
 2services:
 3  seata-server:
 4    image: seataio/seata-server:latest
 5    hostname: seata-server
 6    ports:
 7      - 8091:8091
 8    environment:
 9      - SEATA_PORT=8091
10    expose:
11      - 8091

1FROM openjdk:8
2
3#复制上下文目录下的jar包到容器里  使用COPY命令亦可
4ADD sentinel-dashboard-1.8.0.jar sentinel-dashboard-1.8.0.jar
5
6EXPOSE 8080
7
8#指定容器启动程序及参数   <ENTRYPOINT> "<CMD>"
9ENTRYPOINT ["java","-jar","sentinel-dashboard-1.8.0.jar"]

 1version: '3'
 2services:
 3  sentinel-dashboard:
 4    image: sentinel-dashboard:1.8.0
 5    container_name: sentinel-dashboard
 6    restart: always
 7    environment:
 8      JAVA_OPTS: "-Dserver.port=8080 -Dcsp.sentinel.dashboard.server=localhost:8080 -Dproject.name=sentinel-dashboard -Djava.security.egd=file:/dev/./urandom -Dcsp.sentinel.api.port=8719"
 9    ports: #避免出现端口映射错误，建议采用字符串格式 8080端口为Dockerfile中EXPOSE端口
10      - "58080:8080"
11      - "8719:8719"
12    volumes:
13      - ./root/logs:/root/logs

 1version: '3'
 2services:
 3  xxl-job-admin:
 4    image: xuxueli/xxl-job-admin:2.2.0
 5    restart: always
 6    container_name: xxl-job-admin
 7    depends_on:
 8      - mysql
 9    environment:
10      PARAMS: '--spring.datasource.url=jdbc:mysql://mysql:3306/xxl_job?Unicode=true&characterEncoding=UTF-8 --spring.datasource.username=root --spring.datasource.password=root'
11    ports:
12      - 8067:8080
13    volumes:
14      - ./data/applogs:/data/applogs

 1version: '3'
 2services:
 3  prometheus:
 4    image: prom/prometheus:latest
 5    container_name: prometheus
 6    volumes:
 7      - /opt/docker_compose/monitor/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml
 8      - /opt/docker_compose/monitor/prometheus/alertmanager_rules.yml:/etc/prometheus/alertmanager_rules.yml
 9    ports:
10      - 9090:9090
11    command:
12      - '--config.file=/etc/prometheus/prometheus.yml'
13
14  grafana:
15    image: grafana/grafana
16    container_name: grafana
17    restart: always
18    hostname: grafana
19    volumes:
20      - /opt/docker_compose/monitor/grafana/grafana.ini:/etc/grafana/grafana.ini
21    ports:
22      - "3000:3000"
23
24  alertmanager:
25    image: prom/alertmanager:latest
26    container_name: alertmanager
27    hostname: alertmanager
28    restart: always
29    volumes:
30      - /opt/docker_compose/monitor/altermanager/alertmanager.yml:/etc/alertmanager/alertmanager.yml
31    ports:
32      - "9093:9093"
33
34  prometheus-webhook-alert:
35    image: timonwong/prometheus-webhook-dingtalk:v1.3.0
36    container_name: prometheus-webhook-alertmanagers
37    hostname: webhook-alertmanagers
38    restart: always
39    volumes:
40      - /opt/docker_compose/monitor/prometheus-webhook-dingtalk/config.yml:/etc/prometheus-webhook-dingtalk/config.yml
41      - /etc/localtime:/etc/localtime
42    ports:
43      - "8060:8060"
44    entrypoint: /bin/prometheus-webhook-dingtalk   --config.file=/etc/prometheus-webhook-dingtalk/config.yml  --web.enable-ui

 1version: '3.3'
 2services:
 3  elasticsearch:
 4    image: docker.elastic.co/elasticsearch/elasticsearch:7.5.0
 5    container_name: elasticsearch
 6    restart: always
 7    ports:
 8      - 9200:9200
 9      - 9300:9300
10    environment:
11      - discovery.type=single-node
12      - bootstrap.memory_lock=true
13    network_mode: bridge
14    volumes:
15      - /data/docker_compose/skywalking/es/config/jvm.options:/usr/share/elasticsearch/config/jvm.options:rw
16      - /data/docker_compose/skywalking/es/config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml
17      - /data/docker/elk/elk_elastic/data:/usr/share/elasticsearch/data:rw
18    ulimits:
19      memlock:
20        soft: -1
21        hard: -1
22  oap:
23    image: apache/skywalking-oap-server:8.1.0-es7
24    container_name: oap
25    depends_on:
26      - elasticsearch
27    links:
28      - elasticsearch
29    network_mode: bridge
30    restart: always
31    ports:
32      - 11800:11800
33      - 12800:12800
34    environment:
35      SW_ES_USER: elastic
36      SW_ES_PASSWORD: oasises
37      SW_STORAGE: elasticsearch7
38      SW_STORAGE_ES_CLUSTER_NODES: elasticsearch:9200
39      SW_TRACE_SAMPLE_RATE: 8000
40  ui:
41    image: apache/skywalking-ui:8.1.0
42    container_name: ui
43    network_mode: bridge
44    depends_on:
45      - oap
46    links:
47      - oap
48    restart: always
49    ports:
50      - 8083:8080
51    environment:
52      SW_OAP_ADDRESS: oap:12800

 1version: '2'
 2services:
 3  elk-logstash:
 4    image: docker.elastic.co/logstash/logstash:7.5.0
 5    container_name : elk_logstash
 6    hostname: elk_logstash
 7    stdin_open: true
 8    tty: true
 9    ports:
10      - "5000:5000/udp"
11      -  5001:5001
12    command: logstash --path.settings /etc/logstash -f /etc/logstash/conf.d/logstash.conf
13    external_links:
14      - elasticsearch
15    network_mode: bridge
16    volumes:
17      - /data1/docker/elk/elk_logstash/conf.d:/etc/logstash/conf.d
18      - /data1/docker/elk/elk_logstash/heapdump.hprof:/usr/share/logstash/heapdump.hprof -rw
19      - /data1/docker/elk/elk_logstash/gc.log:/usr/share/logstash/gc.log -rw
20
21  elk-kibana:
22    image: docker.elastic.co/kibana/kibana:7.5.0
23    container_name : elk_kibana
24    hostname: elk_kibana
25    stdin_open: true
26    tty: true
27    ports:
28      - 5601:5601
29    external_links:
30      - elasticsearch
31    network_mode: bridge
32    volumes:
33      - /data1/docker/elk/elk_kibana/config/kibana.yml:/usr/share/kibana/config/kibana.yml
34    environment:
35      - ELASTICSEARCH_URL=http://elasticsearch:9200
